N30Star series capsule house
A vaulted shell with a panoramic end. 29.9 m² · 1 bedroom · 1 living area · 1 bathroom
The N30 is a space capsule house whose semicircular vault gives it an instantly recognisable profile. At 3.6 m it is the widest of the compact models, with a bedroom, living area and bathroom behind a curved glass end.
The curved roof reads well in photographs and from a distance.
A 3.6 m width gives a more generous living area.
The end wall is glazed to frame a single, strong view.
Bathroom, lighting, curtains, the control panel and air conditioning are installed before the module ships.
A welded 80 × 80 × 5 mm rectangular steel frame carries the shell, floor and fit-out as one module. Standard configuration includes a separated wet and dry bathroom, water heater, lighting, curtains, a control panel and air conditioning.
For cold regions the manufacturer offers thicker insulation, trace-heated water lines and auxiliary electric heating. Hot-climate glazing and cooling are confirmed per site.
- Model
- N30
- Series
- Star
- Manufacturer
- Royalstar Smart House
- Exterior (L × W × H)
- 8.3 × 3.6 × 3.2 m
- Floor area
- 29.9 m²
- Layout
- 1 bedroom, 1 living area, 1 bathroom
- Bedrooms / rooms
- 1
- Bathrooms
- 1
- Balcony
- —
- Structure
- Welded 80 × 80 × 5 mm rectangular steel frame
- Shell
- Aluminium alloy panels
- Shell finish
- Baked fluorocarbon coating, five standard colours
- Walls
- 10–20 cm, polyurethane insulated
- Glazing
- Double-glazed Low-E; triple glazing optional
- Base
- Steel base for level footings (footings by others)
- Bathroom
- Separated wet and dry areas, toilet, shower
- Hot water
- Water heater
- Lighting
- Interior lighting and curtains
- Controls
- Room control panel
- Climate
- Air conditioning
- Options
- Cold-climate package, layout changes, finishes, logo
Specifications follow current manufacturer documentation and are confirmed with each quotation.
The N30 is a Star-series space capsule house with a semicircular vaulted roof, a profile that reads clearly in photographs and from a distance. It measures 8.3 × 3.6 × 3.2 m, and its 29.9 m² hold a bedroom, a living area and a bathroom behind a panoramic glass end.
At 3.6 m it is the widest of the compact models, so the living area feels more generous than its length suggests. With the glass at one end, N30 units are usually placed end-on to a single strong view, such as a lake, a valley or the sea, and spaced so that each one keeps that view to itself.
Best for
- Signature glamping suites
- Lakeside and valley retreats
- Holiday rentals that sell on their photographs
How the N30 is quoted and delivered
The price of a N30 depends on its configuration (shell colour, glazing, climate package and fit-out), the number of units, the port of loading and the delivery terms. That is why this page shows no price: you receive a current, dated written quotation that states all of them.
Arrives with the module
- Welded steel frame and base
- Aluminium shell in the chosen colour
- Insulated walls and Low-E glazing
- Bathroom with toilet, shower and water heater
- Lighting, curtains and the room control panel
- Air conditioning
Prepared on your site
- Truck and mobile-crane access to the final position
- Level footings, sized by a local engineer
- Power supply sized for the unit
- Water supply and wastewater connection
- Local planning, building and use permits
Questions about the N30
The N30 measures 8.3 × 3.6 × 3.2 m (L × W × H) and has a floor area of 29.9 m², with one bedroom, one living area and one bathroom.
Both are about 30 m² with one bedroom. The N30 is shorter (8.3 m) and wider (3.6 m), with a vaulted roof and its glass at one end. The F30 is 9.3 × 3.2 m, with a straight body and its glass along one long side.
Towards the main view. On hot sites, also consider the afternoon sun: pointing the glass away from it, or shading it, reduces the cooling load.
Yes. The N30 is fitted out at the factory and ships as one complete module, wrapped and strapped on a flat-rack container or carried as deck cargo. The packing method and port of loading are confirmed in the quotation.
Level footings, usually concrete piers or strip footings, sized by a local engineer for your soil and the unit's weight. Footings, utility connections and approvals are arranged locally.
